Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen

Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen

Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen
Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen
Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen
Product Details:
Place of Origin: CHINA
Brand Name: SCXK
Certification: CB,CE,ROHS,FCC,SASO,UL
Model Number: P2
Payment & Shipping Terms:
Minimum Order Quantity: 6 sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Application: Rental/Fixed Installation Usage Cabinet Size: 300*400mm
LED Chip: Epistar Pixel Density: 250000dots/sqm
ReFresh Rate: 1920Hz-3840Hz Led Lamp: Nationstar Or Kinglight
Scan Mode: 1/32 Scan Control System: LSN/NOVA
Highlight:

P2 led matrix display

,

GOB outdoor led display

       Digtal Small Pitch GOB P2 HD 4K Indoor Full Color Fixed Installation Indoor Video Wall Screen


♦ Application
The Indoor LED Video Wall is highly usable at indoor places like malls, stages, chain stores, hotels, public buildings, bars, restaurants, etc. Its thin size and ultra-lightweight module makes it easy to install at any area without covering much space.

Product description
1. Classical and stable strucrure and performance.
2. Two patent protected strong locks design, realizing combination of reliablity and security.
3. Die-casting aluminum body, light weight for easy transportation and high accuracy installation.
4. Perfectly be compatible with any existing controller and without screen shaking/quick flashing/mosaic problems.
5. Supporting installation of hanging/ground mounting, for stage/TV show/studio, and other event applications.
6. Tool free assembly and disassembly.

♦ Product specification

indoor SMD P2
Lamp size2121
Resolution/mm2
Pixel configurationRGB 3 in 1
Pixel density/pixels/m²250000/m²
Module resolution128x64
Module size/mm320x160
View distance≥2.5m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>1000cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/13
Frame rate60Hz
Refresh frequency>3000Hz
Control modeComputer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡<1100W
Average power:/㎡<280W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%


Features
waterproof
dustproof
moisture proof
anti-collision
anti-UV
avoid LEDs fall off

Application
can be widely used in bar, club, theatre, theatre, multi-function hall, coffee shop, hotel, stage performances, music hall, commercial buildings, airports, shopping malls and other places
Waterproof design
Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen 0

Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

Small Pitch GOB P2 HD Indoor Full Color Fixed Installation Video Wall Screen 1

♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.
After-sales:We will track the products usage and then constantly perfect our products.

About us:
Established in 2005, clients cover more than 50 cuntries, Mainly USA, Europe, dubai, north and mid america, south america, asia. As a high-tech enterprise integrated with scientific research, design, production, maintenance, sales and system integration, we have a professional high-quality technical R & D team,rich experienced engineers and professional product development and design engineers,excellent marketing team, pre and after-sales 24 hours service. Even face with harshest environment,we can carefully choose different suitable materials and make the best offer.
Our team will be forever here to offer you full supports !!!
