Name: P4 Outdoor LED Display 4mm Pixel Pitch 10000h Lifespan
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4
Price: 10000.00 USD
Availability: InStock

Home Products Advertising LED Screens

P4 Outdoor LED Display 4mm Pixel Pitch 10000h Lifespan

Product Details:

Place of Origin:	ShenZhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL
Model Number:	P4

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-15 working days after receive your payment
Payment Terms:	T/T,Western Union
Supply Ability:	5000 sqm per month

Contact Now

Detailed Product Description

Pixels:	4mm	Tube Chip Color:	Full Color
Display Function:	Video	Cabinet:	Iron Or Aluminum For Options
Frame Frequency:	>=60HZ	Average NO Failure:	>=1000hours
Transmiiting Distance:	Internet Cable <100m	Refresh Rate:	>=180HZ
Optimal Viewing Distance:	>=4m	LED Span Lifetime:	10000 H
Highlight:	P4 Flexible Led Display Screen , Outdoor Flexible Led Display Screen , Advertising LED Display Screen

Advertising LED Screen P4 Full Color SMD Outdoor Flexible LED Display Screen

Product Specifications

Pixels	4mm
Tube Chip Color	Full color
Display Function	Video
Cabinet	Iron or Aluminum For Options
Frame Frequency	>=60HZ
Average NO Failure	>=1000hours
Transmitting distance	Internet cable <100m
Refresh Rate	>=180HZ
Optimal viewing distance	>=4m
LED span lifetime	10000 h

High Waterproof Level P4 Outdoor Advertising LED Billboards (3 Years Warranty)

P4 Outdoor LED Module

View Module Details

Type: SMD1919
Driver scan: 1/8 scan
Lamp Brand: Epistar
Arrangement: 1R1G1B
Module Size: 256x128mm
Module Resolution: 64×32=2048 (Dots)

Physical Specifications

Material: Iron
Dimension: 1024*1024*140mm
Weight: 40 KGS
Module Quantity/Cabinet: 4*8=32 pcs
Standard Power supply: G-energy N200V5 (220V) or A-200AF-5 (110V) (Customizable)
Use of environment: outdoor IP65
Cabinet color: Black, White, Grey

Technical Parameters

Module Parameters

Pixel type	Real full color
Pixel color	RGB
Module size	256*128mm
Pixel led	SMD3528
Pixels pitch	4mm
Resolution rate	64*32
Driving way	1/8
Driving IC	MBI5024
Working voltage	DC5V
Power	80W
Working temperature	-30°C - +50°C

Screen Parameters

Material	Aluminum/iron/aluminum die-casting
Color	Black
Size	1024768mm/512512mm
Resolution rate	96*96
Module quantity	3*3
Density	62500dots/m2
White balance luminance	7000-11000cd/m2
Color temperature	6500
Horizontal view angle	110
Vertical view angle	50
Protection grade	Before/after: IP67/IP65
Non-Flatness	<1mm
Module interval	<1mm
Weight	32kg or 6kg
Maximal power/m2	750W
Frame frequency	≥60Hz/s
Refresh frequency	800-3840Hz
Gray grade	102410241024Grade/1073741824
Luminance adjusted	256 grade by auto-optic/color &8 grade by hand
Input signal	RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc
MTBF	>5000h
Life-span	>100000h
Speckles rate	<0.0001

Control System

Production Process

Incoming Inspection
DIP
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

Why Choose Us

Continues Quality: With more than 10 years experience in LED display producing, equipments are updated regularly. What's more, unique standardized and module production ensure our products continuous quality.
Competitive Price: With large scale production capacity and professional production technology, our company have built effective modular production. We always stick to promote the technical innovation and reduce cost to benefit customers.
Fast Delivery: Once we promise the delivery date, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service: Pre-sales: Your purchasing requirements will be highly valued and we'll recommend suitable products to you. After-sales: We will track the products usage and then constantly perfect our products.
