Name: P8 Outdoor LED Display Panel 8mm Pixel Pitch IP65 Waterproof
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P8
Price: 10000.00 USD
Availability: InStock

Home Products LED Billboards

P8 Outdoor LED Display Panel 8mm Pixel Pitch IP65 Waterproof

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL/CB
Model Number:	P8

Payment & Shipping Terms:

Minimum Order Quantity:	2 sqm
Price:	negotiation
Packaging Details:	flight case/wooden case/carton
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability:	3500 sqm per month

Contact Now

Detailed Product Description

Pixels:	8mm	Tube Chip Color:	Full Color
Display Function:	Video	Waterproof:	Ip65
Cabinet:	Iron Or Aluminum For Options	Frame Frequency:	>=60HZ
Average NO Failure:	>=1000hours	Refresh Rate:	>=180HZ
Maximum Power:	850m2	The Optimum:	280w/m2
Highlight:	P8 Outdoor Advertising Led Display Panels , High Brightness Advertising Led Display Panels

P8 Outdoor Advertising LED Display Panels Full Color High Brightness

High resolution LED screen P8 full color LED display for outdoor advertising and digital billboards.

Product Specifications

LED Lamp
Type	SMD3535/2727
Brand	Epistar
Arrangement	RGB 3in1
Chip parameters (Red)	620-625nm IV:800-960mcd
Chip parameters (Green)	520-525nm IV:1350-1650mcd
Chip parameters (Blue)	470-475nm IV:330-400mcd

LED Display Module
Pixel Pitch	8mm
Module Size	256×128mm
Module Resolution	32×16=512 Dots

Pole LED Display
Display Dimension (W×H)	512×512mm
Entire Screen Size (W×H×D)	960×1600×130mm
Cabinet Material	Die Casting Aluminum
Frame Frequency	60 frame/sec
Input Voltage	AC110-220V±10%,50/60Hz
Brightness	≥7000cd/sqm
Viewing Angle	140° (Horizontal), 140° (Vertical)
Minimum Viewing Distance	8m
Color Processing	R(1024)×G(1024)×B(1024)
Total Power Consumption (Max)	1600W/H
Brightness Adjustment	256 color levels, adjustable manually/automatically
Total Power Consumption (Average)	450W/H
MTBF	10,000 hours
Display Function	Text, Graphics, Video
Lifespan	100,000 hours
Refresh Rate	≥1000Hz
Protection Level (front/back)	IP65
Working Temperature	-10℃ to 55℃
Malfunction Dot Rate	<0.0001
Humidity	10% to 90%
Certification	CE, ROHS, FCC, UL, CCC, ISO9001, TUV

Key Features

High Definition: 8mm pixel pitch ensures excellent clarity at close viewing distances with SMD technology providing 140° viewing angle.
Superior Visual Quality: 65,536 grayscale level (16-bit color) with high refresh rate and ultra-high contrast delivers crystal clear images for high-definition content.
Durable Construction: Die-cast aluminum cabinets with IP65 protection ensure reliable outdoor performance.
Energy Efficient: Average power consumption of just 450W/H with automatic brightness adjustment.
Long Lifespan: Designed for 100,000 hours of operation with minimal dot failure rate.

Our Services

Quick response to inquiries within 12 hours
OEM & ODM services available for customized LED displays
72-hour aging test before shipment for product reliability
Custom logo printing available
Comprehensive after-sales service and support

Shipping Information

Express shipping available for samples
Air or sea freight options for bulk orders
Customer-specified freight forwarders accepted
Delivery time: 5-10 days for samples; 10-15 days for bulk orders

Trade Terms

Multiple payment options including TT, Western Union, PayPal, credit cards
Shipping costs quoted per customer requirements
Shipping from Shenzhen port
Minimum order quantity: 1 unit

Why Choose Our LED Displays

Consistent Quality: 10+ years manufacturing experience with regularly updated equipment and standardized production processes.
Competitive Pricing: Large-scale production capacity and efficient manufacturing technology enable cost-effective solutions.
Reliable Delivery: Commitment to promised delivery dates with emergency inventory procedures when needed.
Comprehensive Support: Pre-sales consultation and after-sales tracking to ensure optimal product performance.
