P8 Outdoor LED Billboard Panel 8mm Pixel Pitch Full Color Display

Attribute	Value
Pixel Pitch	8mm
Tube Chip Color	Full color
Led Type	SMD3535
Display Function	Video/Text/Image
Cabinet Size	1024mm*1024mm
Working Voltage	DC5V
Pixel Density	15625 dots/㎡
Driving Mode	1/4 scanning

Designed for high-visibility information display in various outdoor conditions.

• Utilizes ultra-high brightness LEDs and high-quality plastic components
• High-contrast hue for optimal display quality
• Lightweight design for easy installation and removal
• Single-point, single lamp maintenance capability reduces costs
• Constant current LED driving ensures uniform lighting and low power consumption
• 6mm pixel pitch with 32×16 pixels configuration (1R1G1B per pixel)

• High brightness (≥4000cd/㎡) for all-day outdoor visibility
• Extended lifespan (≥100,000 hours)
• Wide viewing angles (≥160° indoor, ≥120° outdoor)
• Intelligent control via computer or WiFi
• Flexible shaping and seamless splicing capabilities compared to LCD displays

Pixel pitch	8mm
LED Type	SMD3535
Pixel composition	1R1G1B
Scan method	1/8
Screen brightness	>6500nits (adjustable)
Average power consumption	305W/sqm
Maximum power consumption	610W/sqm
Module resolution	32dots × 16 dots
Module size	256mm × 128mm
Pixel density	15625dots/sqm
Viewing distance	5-150m
Visual range	>8 m
Grey Grade	≥10 BIT
Color temperature	11000±500K
Viewing angle	Level: 105° vertical: 50°
Life span	>50,000 hours
Working temperature	-10°C to +50°C

• Wind-resistant structure (100 km/h) and earthquake-proof (8 magnitude)
• Excellent waterproof performance with safe, reliable power system
• Customizable components to meet specific requirements
• Environmentally friendly materials used throughout
• Minimum 5-year product lifespan
• 2-5 year warranty coverage
• Comprehensive support including installation, technical assistance, and training

To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.

Packing options: wooden case or flight case available

Shipping methods: air, sea, train, or DHL - you choose
