Name: P6 5mm Pixel Pitch Double Sided LED Billboard IP65 Waterproof
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P5
Price: 10000.00 USD
Availability: InStock

Home Products LED Billboards

P6 5mm Pixel Pitch Double Sided LED Billboard IP65 Waterproof

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB/UL
Model Number:	P5

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,L/C,MoneyGram,D/P
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	5mm	Tube Chip Color:	Full Color
Led Type:	SMD 2727	Display Function:	Video/Text/Image
Waterproof:	IP65	Cabinet:	Steel Or Aluminum For Options
Transmiiting Distance:	Internet Cable <100m	Refresh Rate:	>=1920HZ
Maximum Power:	600㎡
Highlight:	led digital billboards , led screen billboard

Wifi USB Double Sides Led Sign P5 P6 P8 Front Service Led Billboard Full Color

Wifi USB Double Sides Led Sign P6 4x8ft Front Service Led Billboard

LED display, also called LED screen, LED video wall, or LED panel, has become the preferred choice for modern advertising, gradually replacing traditional billboards and light boxes. With high resolution, brightness, and full-color capabilities, LED displays effectively combine text, images, video, and sound to capture attention and maximize advertising impact.

Applications include media advertising, transportation systems, security displays, real estate promotions, and stage show backgrounds.

Module Specifications

Pixel pitch	6mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD 3535
Module size	192x192mm
LED lamp	KingLight or Nationstar
Module resolution	32x32 dots

Cabinet Specifications

Cabinet size	960x960mm
Cabinet material	Ironed steel cabinet
Cabinet weight	32.5kg
Ingress protection	Front/Rear IP65/IP54

Screen Specifications

Pixel density	27778 dots/m²
Brightness	≥5500 cd/m²
Viewing angle	H≥120° V≥60°
Min. viewing distance	6m
Max. power consumption	900W/m²
Avg. power consumption	330 W/m²
Working voltage	110~220VAC±15%
Interface	HUB75
Colors	16.7 million colors
Gray level	65536
Refresh rate	≥1920Hz
MTBF	≥100,000 hours
Lifespan	≥100,000 hours
Protective functions	Over-heat/Over-load/Power-down/Power-leakage/Lightning-protection
Operating temperature	-10℃ ~ +55℃
Storage temperature	-20℃ ~ +55℃

Control System Specifications

Video signal (with video processor)	AV, S-video, VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature	Adjustable by software
Brightness level	256 levels, automatic adjustment by software
Control methods	Computer, video-synchronous, real-time, off-line, wireless, internet
