Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums

Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums

Product Details:
Place of Origin: Shenzhen China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 1 sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: Western Union,T/T,L/C,MoneyGram
Supply Ability: 3000 sqm per month
Contact Now
Detailed Product Description
LED Chip: Episatr Tube Chip Color: Full Color
Waterproof: IP65 Frame Frequency: >=60HZ
Average NO Failure: >=1000hours LED Shape & Size: 3mm SMD3535
Viewing Angle: 160/140 Control System: LSN
Highlight:

Commercial Advertising LED display

,

P10 stadium LED display

,

Commercial Advertising Stadium LED Display

Outdoor HD Full Color SMD P10 Stadium LED Display Commercial Advertising Billboards
Product Specifications
LED Chip Epistar
Tube Chip Color Full color
Waterproof IP65
Frame Frequency ≥60Hz
Average No Failure ≥1000 hours
LED Shape & Size 3mm SMD3535
Viewing Angle 160°/140°
Control System LSN
Basketball Football Club Cricket Stadium Perimeter LED Commercial Advertising Billboards
Stadium LED Display Features:
  • High waterproof level (IP65)
  • Wide viewing angle (160°/140°)
  • Easy installation design
  • High level protection anti-collision
Function and Technology Characteristics:
  • Supports multiple file formats including VGA, Video, AVI, MOV, MPG, DAT, VOB
  • Compatible with various information sources: camera, video, VCD, DVD, LD, TV
  • Adjustable brightness, contrast, and saturation (manual/automatic)
  • Crystal clear picture without flicker or distortion
  • Synchronous display with your PC
  • Advanced correcting technology for distortion
  • Multiple interface options (1 sound, 2 video minimum)
  • PC control via LAN and remote control
  • Multilingual support: English, French, German, Greek, Russian, etc.
Wide Viewing Angle for Broader Reach

The display features a wide viewing angle of 140° which reaches more viewers. The picture quality remains seamless in all directions and at a distance, presenting all viewers with the same high-quality output. This makes it suitable for large gatherings.

Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums 0 Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums 1
Technical Specifications
Parameter Specification
Model Outdoor SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density 10,000/m²
Module resolution 32×16
Module size 320×160mm
View distance ≥10m
Single point brightness adjust Available
Single point color adjust Available
White balance brightness >5000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120°
Vertical view angle 60°
Signal Process bit 10 or 16bit
Grey process 1024×1024×1024 to 65536×65536×65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4
Frame rate 60Hz
Refresh frequency >4200Hz
Control mode Computer synchronous
Brightness adjustment Manual/automatic, 255 steps with no grey loss
Out of control point <1/10000
Working hours ≥72 hours continuous
MTBF >5000 hours
Lifetime 100,000 hours
Life-all-white (brightness halving) 50,000 hours
Operating temperature -20℃ to 45℃
Maximum power <600W/㎡
Average power <200W/㎡
Self-check technology LED spot, communications, power check, temperature monitor (customizable)
Remote monitoring Supervision, fault recording, warning system (customizable)
Software environment Windows NT/1999/XP
Luminous point width deviation <3%
Brightness uniformity <10%
Color uniformity ±0.003 chromaticity coordinate
Power supply AC85-264V (50Hz-60Hz)
Contrast 1000:1
System protection Moistureproof, dustproof, high temp protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Operating humidity 10-95%
Storage humidity 10-95%
Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums 2
Applications
  • Outdoor and indoor advertising, digital billboards
  • Sports halls, fields, playgrounds, schools, churches
  • Airports, bus stations and railway terminals
  • Facades of shopping malls, department stores, banks, car dealerships
  • Architecture and social projects, urban information systems
  • Show-business, concerts, festivals, motor shows and public events
Stadium LED Display Production Process
Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums 3
Packaging and Shipping

Available in wooden case or flight case packaging. Multiple shipping options including sea, air or DHL.

Outdoor P10 SMD LED Display 10000px/m² IP65 for Stadiums 4

Our team provides comprehensive support for all your LED display needs!
