P6 Outdoor LED Display 5500cd/m² Brightness IP65 Waterproof

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P6

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	negotiation
Packaging Details:	flight case/wooden case/carton
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	4500 sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	6mm	Tube Chip Color:	Full Color
Led Type:	SMD2727/3535	Display Function:	Video/Text/Image
Waterproof:	IP65	Cabinet:	Iron Or Aluminum For Options
Viewing Angle:	H:160 V:140	Voltage:	DC5V
Brightness:	5500cd/㎡	Driving Mode:	1/8scan
Highlight:	Full Color Advertising LED Billboards , High Brightness Outdoor LED Signs , P6 Outdoor LED Signs

P6 Outdoor LED Signs Advertising LED Billboards Full Color Digital High Brightness

Digital P6 High Brightness Outdoor Full Color LED Advertising Display Board

Our Advantages

Professional Manufacturer of LED display

OEM service, No MOQ

Easy installation, regular items in Stocks

Offering free design drawing as requested

Remote controlling and adjusting are available

Wooden case or flight case packaging options

24-hour response time

Fast delivery: Usually 6-8 working days

Excellent R&D team, factory price and quality assurance

Production Process

1) Incoming Inspection

2) SMD

3) Plug-in

4) Wave Soldering

5) After Welding

6) Testing

7) Semi Finished Aging

8) Module Assembly

9) Gluing

10) Finished Aging

11) Detection Finishing Warehousing

Outdoor Full Color LED Display Product Specification

Specification	Details
Resolution/mm	6
Pixel configuration	1R1G1B
Pixel density/pixels/m²	27778/m²
Module resolution	32*32
Module size/mm	192x192
View distance	≥6m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>5000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	(1/8)
Frame rate	60Hz
Refresh frequency	>1920Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Maximum power:/㎡	<800W
Average power:/㎡	<300W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%
