Name: P10 Outdoor LED Billboard 10mm Pitch 5000cd/m2 Brightness
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P10
Price: 10000.00 USD
Availability: InStock

Home Products LED Billboards

P10 Outdoor LED Billboard 10mm Pitch 5000cd/m2 Brightness

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P10

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case/wooden case/carton
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram,D/P,L/C
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixels Pitch:	10mm	Tube Chip Color:	Full Color
Cabinet:	Iron Or Aluminum	Frame Frequency:	>=60HZ
Transmiiting Distance:	Internet Cable <100m	Average Power Consumption:	200w/㎡
Module Size:	320mmx160mm	Brightness:	5000-7000cd/m2
Voltage:	DC5V	Pixel Density:	10000dots/sqm
Driving Mode:	1/4 Scan
Highlight:	10000dots/sqm LED Advertising Billboard , P10 LED Advertising Billboard , Outdoor Fixed Installation LED Advertising Billboard

Outdoor Fixed Installation Full Color P10 LED Advertising Billboard with 10000dots/sqm Pixel Density

Product Description

Waterproof P10 Outdoor Digital Advertising Led Video Display 5000cd/㎡ Brightness

Features of P10 Module

Uses ultra-high brightness LED and high-quality plastic pieces
High-contrast hue achieves excellent display quality
Lightweight design for easy installation and removal
Supports single-point, single lamp maintenance with low cost
Constant current LED driving ensures uniform lighting and low power consumption
10mm pixel pitch with 32×16 pixels per module (1R1G1B configuration)

Advantages of P10 Advertising LED Screens

High brightness (≥4000cd/㎡) for all-day outdoor use
Long lifespan (≥100,000 hours)
Wide viewing angles (≥160° indoor, ≥120° outdoor)
Intelligent control system with computer or WiFi control options
Flexible shaping and seamless splicing compared to LCD displays

Technical Parameters

Parameter	Specification
Resolution	10mm
Pixel configuration	1R1G1B
Pixel density	10000 pixels/m²
Module resolution	32×16
Module size	320×160mm
Viewing distance	10-300m
White balance brightness	>5000cd/㎡
Color temperature	6500K-9500K
Viewing angles	120° horizontal, 60° vertical
Refresh frequency	3000Hz
Working temperature	-20°C to +50°C
Power consumption	<600W/m² (max), <200W/m² (avg)
Lifespan	>100,000 hours
Warranty	2 years quality warranty, 10 years spare parts support
