Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE,ROHS, FCC.UL.CUL |
Model Number: | P5 |
Minimum Order Quantity: | one cabinet sand one module can be avaiable. |
---|---|
Price: | Negotiable |
Packaging Details: | wooden box, flight case, paper box |
Delivery Time: | within 7-10day |
Payment Terms: | D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Cabinet Size: | 640mm X640mm | Module Size: | 320mm X160mm |
---|---|---|---|
Warranty: | 3 Years | Refresh Rate: | 2500hz |
Led Chip: | Epistar | Color: | Full Color |
Scan Way: | 1/16 Scan | Dot Density: | 40000dots/sqm |
Use: | Advertising Publish, Shopping Mall, Welcome Display, Restaurant & Hotel Supplies | ||
Highlight: | 640mm X640mm LED Signage,Full Color LED Signage,40000 Points/Square Meters LED Signage |
SMD2121 Full Color LED Signs 640mm x640mm cabinet 40000 dots / sqm
1. How to choose the led display most suitable for my project? And what is the best price you can offer?
First of all, you’d better to know the application of the screen ( Indoor or Outdoor); the size of the screen would be ( Length & Height); what will the screen will be used for ( advertising, on live event, need to be installed somewhere permanently or for rental use). We will check out the best price and screen upon your conditions
2. What is your lead time?
Under the normal condition, sample order for 3-7 working days, regarding mass order, if we have available raw material,the lead time will around 15 working days, otherwise, would be 20-30 working days
3. What is your payment method?
Our usually practice for payment is by T/T for the mass order and also we do the trade assurance ( Provided by Alibaba and Gteak to make sure your payment, shipment, goods’ quality security and ensurance)
4. What is your shipping and packing way?
Our standard packing for modules are carton box and for the led cabinet, we do wood box or flight case as per customers’ requests. For the mass order ( fit for a container), we do shipment by Sea and for others usually by express or airlin
5. Can i place a sample order before i decide to do the mass production?
Yes, we acceptable sample orders, please let us know your detail request then we will send you the sample asap for confirmatio
6. Can i have a free sample?
We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent
the detailed paramter as follows
The die cast aluminum cabinet hanging and rental usage led display | ||||||
Number | Drive mode | module size | Resolution | cabinet size | Led standard | pixel density |
P3.91 | 1/8 scan | 250x250mm | 64x64 | 500x500mm | 3 in 1 | 65410 |
p4 | 1/8 scan | 256x128mm | 64x32 | 512x512mm | 3 in 1 | 62500 |
P4.81 | 1/8 scan | 250x250mm | 52x52 | 500x500mm | 3 in 1 | 43222 |
P5 | 1/8 scan | 320x160mm | 64x32 | 640x640mm | 3 in 1 | 40000 |
p6 | 1/8 scan | 192x192mm | 32x32 | 576x576mm | 3 in 1 | 27777 |
p8 | 1/8 scan | 256x128mm | 32x16 | 512x512mm | 3 in 1 | 15625 |
p10 | 1/4scan | 320x160mm | 32x16 | 640x640mm | 3 in 1 | 100000 |
The indoor die cast aluminum cabinet hanging and rental usage led display | ||||||
P2 | 1/32scan | 128X64mm | 64x32 | 512x512mm | 3 in 1 | 250000 |
p2.5 | 1/32scan | 160x160mm | 64x64 | 480x480mm | 3 in 1 | 160000 |
p3 | 1/32scan | 192x192mm | 64x64 | 576x576mm | 3 in 1 | 111111 |
p4 | 1/32scan | 256x128mm | 64x32 | 512x512mm | 3 in 1 | 62500 |
p5 | 1/16scan | 320x160mm | 64x32 | 640x640mm | 3 in 1 | 40000 |
p6 | 1/16scan | 192x192mm | 32x32 | 576x576mm | 3 in 1 | 27777 |
Parameter | P5 | |
Basic Parameter | Pixel Configuration | SMD 3 in 1 |
Pixel Pitch (mm) | 5.0mm | |
Pixel Density | 40000 pixels/m2 | |
Cabinet Resolution | 128*128 pixels | |
Cabinet Dimension(W*H*D) | 640*640mm | |
Weight (kg/sqm) | 22kg | |
Cabinet Material | Die-cast Aluminum | |
Optical Parameter | Color Grayscale (bit) | 16bit |
Frame Frequency (Hz) | 50/60Hz | |
Brightness (nit) | 2,000 cd/m2 | |
Viewing angle | 140°/140° | |
Flatness error | ≤0.5mm | |
Using Parameter | Working Voltage (V) | AC: 100-240V(50/60 Hz) |
Max. Power Consumption | 220 W/cabinet | |
Storage Temperature (°C) | -20~60 | |
Operating Temperature (°C) | -10~40 | |
Storage Humidity (RH) | 10%~90% | |
Operating Humidity (RH) | 10%~90% | |
IP Rating (Front / Rear) | IP43 | |
Lifetime Typical Value (hrs) | 50,000 |
