Name: P4 SMD 2121 Indoor LED Video Wall Screen 4mm Pitch
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4
Price: 10000.00 USD
Availability: InStock

Home Products SMD LED Screen

P4 SMD 2121 Indoor LED Video Wall Screen 4mm Pitch

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL
Model Number:	P4

Payment & Shipping Terms:

Minimum Order Quantity:	3 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	Western Union,MoneyGram,D/P,T/T
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixels Pitch:	4mm	Tube Chip Color:	Full Color
Led Type:	SMD2121	Cabinet:	Iron Or Aluminum For Options
Refresh Rate:	720HZ	Module Size:	320*160mm
Cabinet Size:	640640mm/960960mm	Module Resolution:	6432/8040
Viewing Angle:	H:160 V:140
Highlight:	led display smd , outdoor smd led display

Clear SMD 2121 P4 Indoor LED Video Wall Screen for Events / Advertising

Product Specifications

Pixels pitch	4mm
Tube Chip Color	Full color
Led Type	SMD2121
Cabinet	Iron or Aluminum For Options
Refresh Rate	720HZ
Module size	320*160mm
Cabinet size	640640mm/960960mm
Module resolution	6432/8040
Viewing angle	H:160° V:140°

Product Features

P4 SMD LED Screen

LED: Uses well-known international brand LEDs with wide viewing angle, high brightness, minimal attenuation, excellent heat dissipation, and vivid colors.
Driving IC: Features premium brands like Taiwan MBI and Japanese Toshiba, eliminating issues like dark bright or virtual light.
Power supply: Industrial-strength brand with 20% maximum power reserve, less than 5% voltage fluctuation, and high stability.
Connector: Aerial grade brands ensure stable power and signal transmission.
PCB Board: 4-layer design for enhanced durability and performance.
Easy installation: 100 cabinets can be installed in one hour by one person, with cabinet replacement possible within 50 seconds.

Technical Specifications

Pixel configuration	1R1G1B
Pixel density	62500/m²
Module resolution	64x32
Module size	320x160mm
View distance	4-300m
White balance brightness	>1000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120°
Vertical view angle	60°
Refresh frequency	>3000Hz
Frame rate	60Hz
Working temperature	-20°C to 45°C
Maximum power	<750W/㎡
Average power	<250W/㎡
Lifetime	100,000 hours
