Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising

Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising

Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising
Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising
Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising
Product Details:
Place of Origin: ShenZhen in China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/CB
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 10mm LED Chip Color: Epistar
Led Type: SMD 3528 Display Function: Video/Text/Image
Waterproof: Ip65 Cabinet: Steel Or Aluminum For Options
Average NO Failure: >=1000hours Transmiiting Distance: Internet Cable <100m
The Optimum: 600w/m2
High Light:

perimeter led display

,

led perimeter advertising boards

High Resolution Advertising Stadium Led Display Screen Iron Soft Mask Cabinet





Stadium LED Display Function and Technology Character:



1. Support multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on

2. The screen can get singal of camera, video, VCD, DVD, LD, TV and so on.

3. Brightness, contrast, saturation can be adjusted automatically by itself and manual.

4. Clear picture without flicker and distortion.

5. Show everything with your PC synchronously.

6. Super correcting technology for distortion.

7. One interface for sound signal and two ports for video signal at least.

8. Connected and controlled by PC via Lan and remote control.

9. Multiform language are available,such as English, French, Germany, Spanish, Russian and so on



Stadium led display features:



1.High waterproof level.

2. Wide viewing angle

3. Easy installation design

4. High level protection anti-collision.



♦Wide viewing angle for broader Reach:



The display features a wide viewing angle of 140° which reaches more viewers. The picture quality remains seamless in all direction and at a distance, presenting all viewers the same highly quality outputs. This makes it suitable for large gathering.

Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising 0

Technical specification



outdoor SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/m²
Module resolution 16x16
Module size/mm 160x160
View distance 9-500m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/4)
Frame rate 60Hz
Refresh frequency >4200Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <950W
Average power:/㎡ <350W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





♦ Packaging and shipping



Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

Perimeter led display P5 p10 with aluminum cabinet football stadium led screen outdoor for advertising 1





Our Services


1)Reply your inquiry in 24 working hours.

2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time
.





Our team will be forever here to offer you full supports !!!
