Name: P8 Outdoor LED Screen 8mm Pitch 5000cd Brightness
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P8
Price: 10000.00 USD
Availability: InStock

Home Products Advertising LED Screens

P8 Outdoor LED Screen 8mm Pitch 5000cd Brightness

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL/CB
Model Number:	P8

Payment & Shipping Terms:

Minimum Order Quantity:	2sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixels Pitch:	8mm	Cabinet Material:	Iron Or Die-casting Aluminum
Module Size:	320mm*160mm	Working Voltage:	DC5V
Warranty:	2~5 Years	Pixel Density:	15625dots/sqm
Driving Mode:	1/4scaning	Brightness:	≥5000
Highlight:	P8 Outdoor Led Advertising Signs , Epistar Outdoor Led Advertising Signs , 4000cd/㎡ Led Outdoor Advertising Screens

P8 Outdoor Waterproof LED Advertising Screens 4000cd/㎡ Roadway Full Color

All-Weather Resistant Giant P8 Outdoor LED Advertising Billboard for Releasing Information

Features of P8 Module

Uses ultra-high brightness LED and high-quality plastic pieces
High-contrast hue achieves excellent display quality
Lightweight design for easy installation and removal
Single-point, single lamp maintenance capability with low cost
Constant current LED drive for uniform lighting and low power consumption
6mm pixel pitch with 32×16 pixels (1R1G1B per pixel)

Advantages of P8 Advertising LED Screens

High brightness (≥4000cd/㎡) for 24/7 outdoor visibility
Long lifespan (≥100,000 hours)
Wide viewing angles (≥160° indoor, ≥120° outdoor)
Intelligent control system with computer or WiFi operation
Flexible shaping and seamless splicing compared to LCD displays

Technical Parameters

Pixel Pitch	8mm
LED Type	SMD3528
Pixel Composition	1R1G1B
Scan Method	1/8
Screen Brightness	>6500nits (adjustable)
Average Power Consumption	305W/sqm
Maximum Power Consumption	610W/sqm
Module Resolution	80dots × 40 dots
Module Size	320mm × 160mm
Pixel Density	15625dots/sqm
Viewing Distance	5-150m
Pixel Weight	350g
Pixel Power (max)	16 W/PCS
Visual Range	>8 m
Grey Grade	≥10 BIT
Color Temperature	11000±500K
Viewing Angle	Level: 105° vertical: 50°
Life Span	>50,000 hours
Working Temperature	-10°C to +50°C
