P10 Outdoor LED Billboard 10mm Pixel 600W/m² Full Color Display

The high resolution LED screen delivers exceptional quality pictures and videos to broad audiences. Ideal for outdoor advertising applications including banks, stages, promotions, exhibitions, highways, stations, stadiums, and other outdoor venues.

Designed for outdoor installations, this display produces high brightness output with exceptional clarity. The PH10 LED Display's superior brightness and high definition capabilities ensure outstanding image quality, making it perfect for stages, banks, highways, promotions, stations, stadiums, and other outdoor locations.

Outdoor P10
Lamp size	3535
Resolution/mm	10
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	10000/m²
Module resolution	32x16
Module size/mm	320x160
View distance	≥9m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>5500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	constant driving static
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<600W
Average power:/㎡	<200W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)

• OEM service, No MOQ.
• Easy installation, regular items in stocks.
• Offering free design drawing as requested.
• Remote controlling and adjusting are available.
• Wooden case or flight case, you are the boss.
• Your reply will be replied within 24 hours.
• Fast delivery: Usually 6-8 working days.
• Excellent R&D team, factory price and assure you quality goods.

1. Incoming Inspection
2. SMD
3. Plug-in
4. Wave Soldering
5. After Welding
6. Testing
7. Semi Finished Aging
8. Module Assembly
9. Gluing
10. Finished Aging
11. Detection Finishing Warehousing

Wooden case or flight case package are available.
Shipping by sea, air or DHL, multiple shipping ways for your choice.

With more than 10 years experience in LED display production, our equipment is regularly updated. Our unique standardized and modular production ensures consistent product quality.

Our large-scale production capacity and professional production technology enable effective modular production. We continuously promote technical innovation and cost reduction to benefit our customers.

We honor our delivery commitments and implement special procedures like emergency inventory to maintain uninterrupted product supply.

Pre-sales: We carefully consider your purchasing requirements and recommend suitable products.
After-sales: We track product usage to continuously improve our offerings.

Our team will be forever here to offer you full supports!
