Full Color Outdoor SMD P5 RGB Stadium LED Display Screen Fixed Installed
Product Specifications
| Attribute |
Value |
| Pixel Pitch |
5mm |
| Led Type |
SMD 2727 |
| Display Function |
Video/Text/Image |
| Waterproof |
IP65 |
| Cabinet |
Die-casting aluminum or Iron |
| Frame Frequency |
>=60HZ |
| Average NO Failure |
>=1000hours |
| Brightness |
more than 5000cd/m² |
Football Club Stadium P5 Digital Big LED Live Video Wall Billboard Basketball Stadium Sports Score Board
Detailed Specifications
Pitch size: 5mm
Module size: 320mm*160mm
Panel pixel(dots): 64*32
Pixel configuration: 1Red,1Green,1Blue
Color scale: 256-65536grade/16777216colors
Pixel density: 10000 pixel dots
View angle(H/V): 160/120 degree
Brightness: ≥6500cd/square meter
View distance: 5-150m
Power consumption: 100-1200W/square meter
Net weight: 8kg/pcs
Operating temperature: -25°C~+60°C
Operating humidity: 10%--95%RH
Life time: ≥100,000hours
Exchange frame speed: >150frames per second
Refresh frame frequency: 1920-3840Hz
Control distance: 100m (without relay),single mode fiber: 20000m,multi mode fiber:500m-20km
Power: 110V/220V/380V±15% 50Hz
Operating system: Windows98/Me/2000/Xp
Drive mode: constant current driving
Display mode: VGA640X480--VGA1600X1024
Protections for outdoor display: IP65
Accepting signal: PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
Key Features of Stadium Perimeter LED Screen
- High refresh rate: Up to 3800Hz refresh rate ensures flicker-free performance under professional camera conditions (1/2800 seconds) for ultra high-definition image quality.
- Standard size modules: 320mm×160mm panels allow for quick assembling, maintenance, and easy pixel pitch changes (P5mm, P8mm, P10mm) without structural modifications.
- Exquisite cabinet design: Lightweight construction with quick locks, delicate structure for gap-free installation, and humanization handlebar design for easy movement.
- Independent support structure: Rotatable and adjustable design withstands strong impacts and allows flexible angle adjustment (60°-90° range) to suit various site conditions.
- Soft mask design: Unique soft protective pad enhances safety by protecting individuals who might come into contact with the screen.
- Ultra light weight cabinet: At only 28.5kg, the outdoor stadium display is easy to transport, install, and saves on labor costs.
- Waterproof performance: Special air inlet and waterproof structure provides excellent water resistance while maintaining effective heat dissipation and quiet operation.
- IP65 protection level: All-weather outdoor performance with anti-ultraviolet protection, ensuring durability and reliability in any weather condition.
Packaging and Shipping
Wooden case or flight case package available.
Shipping options: sea, air or DHL available.
