Name: P5 Outdoor Waterproof LED Display for Stadiums IP65 5000cd/sqm
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P5
Price: 10000.00 USD
Availability: InStock

Home Products Stadium LED Display

P5 Outdoor Waterproof LED Display for Stadiums IP65 5000cd/sqm

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P5

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	5mm	Led Type:	SMD 2727
Display Function:	Video/Text/Image	Waterproof:	IP65
Average NO Failure:	>=1000hours	Dot Density:	40000 Dots/ Sqm
Viewing Angle:	140/120	Brightness:	≥5000 Dots/ Sqm
Control System:	LSN
Highlight:	Digital Big Stadium LED Dispay , Waterproof Stadium LED Dispay , P5 Stadium LED Dispay

Outdoor Full Color Waterproof P5 Digital Big Stadium LED Display Video Score Board

Product Attributes

Attribute	Value
Pixel Pitch	5mm
Led Type	SMD 2727
Display Function	Video/Text/Image
Waterproof	IP65
Average NO Failure	>=1000hours
Dot density	40000 dots/ sqm
Viewing angle	140/120
Brightness	≥5000 dots/ sqm
Control system	LSN

Product Description

Football Club Stadium P5 Digital Big LED Live Video Wall Billboard Basketball Stadium Sports Score Board

Specification

Pitch size	5mm
Module size	320mm160mm/160mm160mm
Panel pixel(dots)	64*32
Pixel configuration	1Red,1Green,1Blue
Color scale	256-65536grade/16777216colors
Pixel density	40000 pixels/square meter
View angle(H/V)	160/120 degree
Brightness	≥6500cd/square meter
View distance	5-150m
Power consumption	100-1200W/square meter
Net weight	8kg/pcs
Operating temperature	-25°C~+60°C
Operating humidity	10%--95%RH
Life time	≥100,000hours
Exchange frame speed	>150frames per second
Refresh frame frequency	1920-3840Hz
Control distance	100m (without relay),single mode fiber: 20000m,multi mode fiber:500m-20km
Power	110V/220V/380V±15% 50Hz
Operating system	Windows98/Me/2000/Xp
Drive mode	constant current driving
Display mode	VGA640X480--VGA1600X1024
Protections for outdoor display	IP65
Accepting signal	PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

Product Features

High refresh rate: Up to 3800Hz refresh rate ensures flicker-free display under professional camera conditions
Standard size modules: 320mm×160mm modules for easy assembly and maintenance
Exquisite cabinet design: Lightweight with quick locks and humanization handlebar for easy installation
Independent support structure: Adjustable installation angle from 60° to 90°
Soft mask design: Protective padding ensures safety for players and spectators
Ultra light weight: Only 28.5kg for easy transportation and installation
Waterproof performance: Special air inlet and waterproof structure with IP65 protection
