Name: SMD3535 LED Dance Floor Panel 4.81mm Pixel IP65 Waterproof
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4.81
Price: 10000.00 USD
Availability: InStock

Home Products LED Dance Floor

SMD3535 LED Dance Floor Panel 4.81mm Pixel IP65 Waterproof

Product Details:

Place of Origin:	ShenZhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL
Model Number:	P4.81

Payment & Shipping Terms:

Minimum Order Quantity:	3 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-15 working days after receive your payment
Payment Terms:	T/T,Western Union
Supply Ability:	5000 sqm per month

Contact Now

Detailed Product Description

Pixels:	4.81mm	Tube Chip Color:	Full Color
Led Type:	SMD3535	Display Function:	Video
The Optimum Viewing Angel:	H:360°, V:360°	Relative Humidity:	≤95%RH
IC:	MBI 5024 IC	Rated Power/average Power:	400W/240W
Scan Mode:	Static Scan	Brightness:	Over Than 3000
Highlight:	interactive dance floor , light up dance floor

SMD3535 Sound Active DJ LED Disco Dance Floor Warm White Beam Panels

Product Attributes

Attribute	Value
Pixels	4.81mm
Tube Chip Color	Full color
Led Type	SMD3535
Display Function	Video
The optimum viewing angle	H:360°, V:360°
Relative humidity	≤95%RH
IC	MBI 5024 IC
Rated power/Average power	400W/240W
Scan mode	Static scan
Brightness	Over than 3000

Product Description

SMD3535 sound active DJ LED disco dance floor panels with warm white beam effect.

Features

Display 50 kinds of patterns
Display all video formats
Display all kinds of text
Built-in interactive dynamic effects that respond to footsteps

Applications

Architectural/retail spaces, stages, productions, night clubs, DJ parties, live concerts, award functions, art galleries, museums and more.

Product Specifications

LED Specifications
Type	SMD
LED Standard	Real Pixel (1R1G1B)
Red Wavelength	625-630nm
Green Wavelength	515-530nm
Blue Wavelength	465-475nm
Module Specifications
Pixel Pitch	4.81mm
Resolution	52x52 dots
Module Size	250x250mm
Cabinet Specifications
Cabinet Size (W*H)	500x1000mm
Cabinet Resolution	104x208 dots
Pixel Density	43222 dots/㎡
Cabinet Weight	≤6.5kg
Material	Die casting aluminum
Flatness of cabinet	≤0.3mm
Screen Parameters
Color/Brightness Calibration	Yes
Color Temperature (K)	3000-10000
Light Centre Distance Deviation	＜3%
Brightness Uniformity	≥97%
Color Uniformity	Within ±0.003C×,Cy
Contrast Ratio	5000:1
View Angle	Horizontal 160°/Vertical 140°
Input Voltage	AC100~240V (50-60Hz)
Power Consumption	Max:800w/㎡ Avg:280w/㎡
Driving Method	13 scanning
Protection Level	IP65 waterproof
Grey Scale Levels	R(256) G(256) B(256)
Life Span	100,000 Hrs
Temperature-Operating	-20 -- 50℃
Humidity-Operating	10 - 90%
Features	Anti-slip, anti-collision, big load-bearing capacity
Usage	LED floors, LED wall background
Display function	Text, picture, video

Production Process

Incoming Inspection
SMD
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Our Advantages

Professional Manufacturer of LED display
OEM service, No MOQ
Easy installation, regular items in Stocks
Offering free design drawing as requested
Remote controlling and adjusting are available
Wooden case or flight case packaging options
Your reply will be replied within 24 hours
Fast delivery: Usually 6-8 working days
Excellent R&D team, factory price and quality assurance

Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

Methods for Quality Assurance

Aging: 100% fully tested for 72 hours with 256 grey level

Vibration Testing: 3-5 mins up and down in 5mm range

Our Factory

Why Choose Us

Continuous Quality: 12+ years experience in LED display production with regularly updated equipment and standardized module production.

Competitive Price: Large scale production capacity and professional technology allow us to offer cost-effective solutions.

Fast Delivery: We maintain strict delivery schedules and use emergency inventory when needed.

Perfect Service: Comprehensive pre-sales consultation and after-sales support with product usage tracking.
