Big Led Display Screen Outdoor Full Color Novastar Control Advertising Led Billboard
High Quality Big 4x5m Led Display Screen Novastar Wifi USB Control Advertising Led Billboard
PH10 DIP Outdoor Advertising LED Display
The high resolution LED screen delivers exceptional quality pictures and videos to broad audiences. Ideal for outdoor advertising applications including banks, stages, promotions, exhibitions, highways, stations, stadiums and other outdoor venues.
High Brightness, High Reliability
Designed for outdoor installations, the PH10 LED Display features high brightness and high definition output, ensuring excellent visibility even in direct sunlight. Perfect for stages, banks, highways, promotions, stations, stadiums and other outdoor applications.
Product Specification
| Specification |
Outdoor P10 |
| Lamp size |
3535 |
| Resolution/mm |
10 |
| Pixel configuration |
RGB 3 in 1 |
| Pixel density/pixels/m² |
10000/m² |
| Module resolution |
32x16 |
| Module size/mm |
320x160 |
| View distance |
≥10m |
| Single point brightness adjust |
Can be added |
| Single point color adjust |
Can be added |
| White balance brightness |
>5000cd/㎡ |
| Color temperature |
6500K-9500K |
| Horizontal view angle |
120(degrees) |
| Vertical view angle |
60(degrees) |
| Signal Process bit |
10 or 14 bit |
| Grey process |
1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances |
Internet cable:100m, multimembrane:500m, monofilm:5km |
| Driving mode |
Constant driving current |
| Scanning mode |
constant driving static |
| Frame rate |
60Hz |
| Refresh frequency |
>3000Hz |
| Control mode |
Computer synchronous |
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point |
<1/10000 |
| Working hours |
≥72hours |
| Mean Time Between Failure |
>5000hours |
| Life time |
100000hours |
| Life-all-white(brightness halving) |
50000hours |
| Environment temperature range |
Operating temperature range: -20-45℃ Storing temperature range: -10-55℃ |
| Maximum power:/㎡ |
<600W |
| Average power:/㎡ |
<200W |
| Self-check technology |
LED spot self-check, communications check, power check, temperature monitor(need customization) |
Our Advantages
Professional Manufacturer of LED Display
- OEM service, No MOQ
- Easy installation, regular items in Stocks
- Offering free design drawing as requested
- Remote controlling and adjusting are available
- Wooden case or flight case packaging options
- 24-hour response time for inquiries
- Fast delivery: Usually 6-8 working days
- Excellent R&D team, factory Price and quality assurance
Production Process
1) Incoming Inspection → 2) SMD → 3) Plug-in → 4) Wave Soldering → 5) After Welding → 6) Testing → 7) Semi Finished Aging → 8) Module Assembly → 9) Gluing → 10) Finished Aging → 11) Detection Finishing Warehousing
Packaging and Shipping
Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping options available.
Why Choose Us
Continuous Quality: With over 10 years experience in LED display production, regularly updated equipment and standardized module production ensure consistent product quality.
Competitive Price: Large scale production capacity and professional technology enable cost-effective solutions for customers.
Fast Delivery: Committed to promised delivery dates with emergency procedures available to maintain supply.
Perfect Service: Comprehensive pre-sales consultation and after-sales support with ongoing product improvement.
Our team is committed to providing you with full support!
