Name: P10 Outdoor Stadium LED Display IP65 960x960mm Cabinet
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P10
Price: 10000.00 USD
Availability: InStock

Home Products Stadium LED Display

P10 Outdoor Stadium LED Display IP65 960x960mm Cabinet

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P10

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	4000 sqm per month

Contact Now

Detailed Product Description

LED Chip::	Nationstar	Pixel Dots:	10000dots/sqm
Module Size:	320x160mm	Brightness:	5000-7000cd/sqm
Warranty:	3 Years	Cabinet Size:	960*960mm
Control System:	LSN	LED Arrangement:	RGB 3 In 1
Highlight:	IP65 Stadium LED Display , Full Color Stadium LED Display , P10 Stadium LED Display

China Full Color Outdoor Stadium LED Display Screen P10 IP65 960x960mm Cabinet

Product Specifications

Attribute	Value
LED chip	Nationstar
Pixel dots	10000dots/sqm
Module size	320x160mm
Brightness	5000-7000cd/sqm
Warranty	3 years
Cabinet size	960*960mm
Control system	LSN
LED arrangement	RGB 3 in 1

Outdoor Football Stadium Ground LED Screen P10 Advertising Perimeter Display

Stadium LED Display Features

The SMD Sport Field LED Screen features integrated pull-down rear back support brackets enabling easy transportation in flight cases and simple installation. Simply pull down the brackets onto the floor to support the sport field LED screen.

Premium Quality Construction

All chips are sourced from leading global suppliers. We maintain strict quality control with LED chips provided by Epistar and quality ICs from MBI, TMS, PWM and Mingyang.

Advanced Control System

The display features Novastar control system ensuring high-quality output, excellent resolution, fast loading times and high refresh rates. Known for its stability and reliability, making it ideal for various advertising applications.

Technical Specifications

Specification	Detail
Model	Outdoor SMD P10
Resolution	10mm
Pixel configuration	1R1G1B
Pixel density	10000/m²
Module resolution	16x16
Module size	160x160mm
View distance	10-500m
White balance brightness	>8000cd/㎡
Color temperature	6500K-9500K
Viewing angles	Horizontal: 120°, Vertical: 60°
Frame rate	60Hz
Refresh frequency	>4200Hz
Working temperature	-20°C to 45°C
Power consumption	Max: <950W/㎡, Avg: <350W/㎡
Lifespan	100,000 hours
