P8 Outdoor Waterproof Full Color SMD3535 Shopping Mall LED Advertising Screens
Product Specifications
| Attribute |
Value |
| Pixels Pitch |
8mm |
| LED Chip |
Epistar, Kinglight |
| Cabinet Material |
Iron or Die-casting Aluminum for Option |
| Module Size |
320mm*160mm |
| Working Voltage |
DC5V |
| Warranty |
2~5 years |
| Pixel Density |
15625dots/sqm |
| Driving Mode |
1/4scaning |
| Certificates |
CE,RoHs,FCC,ISO |
Professional Outdoor Digital SMD LED Screen with 3 Years Warranty
IP65 Waterproof Protection
The P8 SMD Outdoor LED Billboard features special waterproof design that protects against water and dust ingress. With IP65 rating, it delivers high-quality performance in all outdoor conditions.
Easy Installation & Transport
The rugged cabinet design makes transportation and installation simple. Lightweight construction reduces shipping costs while maintaining durability. Available in multiple standard cabinet colors.
Key Advantages
- High brightness (≥4000cd/㎡) for all-day outdoor visibility
- Extended lifespan (≥100,000 hours)
- Wide viewing angles (≥160° indoor, ≥120° outdoor)
- Dual control options: direct computer control or WiFi
- Flexible shaping and seamless splicing capabilities
Technical Parameters
| Pixel pitch |
8mm |
| LED Type |
SMD3535 |
| Pixel composition |
1R1G1B |
| Scan method |
1/8 |
| Screen brightness |
>6500nits (adjustable) |
| Average power consumption |
305W/sqm |
| Maximum power consumption |
610W/sqm |
| Module resolution |
32dots × 16 dots |
| Module size |
256mm × 128mm |
| Pixel density |
15625dots/sqm |
| Viewing distance |
8-150m |
| Visual range |
>8m |
| Viewing angle |
Level: 105° vertical: 50° |
| Life span |
>50,000 hours |
| Working temperature |
-10°C to +50°C |
Outstanding Outdoor Performance
Engineered for superior outdoor performance, the P8 display delivers crisp, high-resolution visuals in all environmental conditions. Perfect for displaying images, videos, and text with exceptional clarity.
Product Advantages
- Wind resistant up to 100 km/h and earthquake resistant up to magnitude 8
- Excellent waterproof performance with reliable power system
- Customizable components to meet specific requirements
- Environmentally friendly materials throughout
- Extended product lifespan exceeding 5 years
- Comprehensive 2-5 year warranty
- Additional services including installation, technical support, and training
Control System
Certifications
Packing & Shipping
Packing options include wooden cases or flight cases. Shipping methods available by air, sea, train, or DHL - we accommodate your preferred logistics solution.
Frequently Asked Questions
How can I place an order?
Please provide detailed requirements for prompt quotation. For design discussions, contact us via Skype, email, or WhatsApp for immediate response.
What types of displays do you provide?
We offer indoor, outdoor, mobile, rental, stage, and advertising LED displays with customization options available.
What is the typical lead time?
Standard lead time is 7-17 days after payment confirmation. Some items may ship within 7 days if in stock.
What warranty do you offer?
2-5 year warranty covering LED modules, receiving cards, control cards, and power supplies against manufacturing defects.
How do you ensure product quality?
All products undergo 72-hour testing before shipping. Strict quality control measures are implemented at every production stage.
Do you provide technical support?
We offer free training on screen setup, parameter configuration, and content broadcasting. Our English-speaking engineers provide direct assistance when needed.
